Single leaf flap swing check valve
We are specializing in butterfly valve, check valve, gate /Knife gate valve. we have professional pre-sale and after-sale technical support and perfect services.
Key Words：
Single leaf flap swing check valve
single leaf flap swing check valve
Classification：
E-mail:
Product details
| Brand | VEYRON |
| Product name | SINGLE FLAP SWING CHECK VALVE |
| material | WCB-SS body/SS-WCB disc/EPDM seat |
| Port size | DN40-DN600 |
| Working pressure | PN10.PN16 |
| Application | water |
| guarantee period | 18 month |
| Face to face | ISO5752 |
| Flanged drilling standard | BS EN;DIN;ANSI;JIS;EN1092-2 |
Mechanical Simplicity & Low Head-Loss Veyron Valve’s Single Leaf Flap Check Valve is the definitive choice for systems where maximizing flow efficiency is the primary KPI. Designed with a simplified internal pivot, the single flap swings entirely out of the flow stream, ensuring a full-bore passage that minimizes pump energy consumption. This "flap-style" architecture is particularly effective in low-pressure irrigation and gravity-fed drainage systems where a standard spring-loaded valve might create unnecessary back-pressure. Its rugged, streamlined design reduces internal turbulence, making it a "fit-and-forget" solution for heavy-volume fluid transfer.
Single thin leaf swing check valve, PN16,PN25.PN40.PN64,carbon steel and stainless steel material.sealed by EPDM,NBR,Viton,etc,three sealing o-ring or just one,up to inquiry. Fast production time and quick shipment,long using life.
