Ball check valve
We are specializing in butterfly valve, check valve, gate /Knife gate valve. we have professional pre-sale and after-sale technical support and perfect services.
Key Words：
Ball check valve
Classification：
E-mail:
Product details
Simplicity as the Ultimate Sophistication
In complex pumping circuits, the most frequent failure points are often the most mechanical. Veyron Valve’s Industrial Ball Check Valve eliminates the need for hinges, pins, and bushings—the typical culprits of seizure and fatigue in traditional check valves. By utilizing a single, elastomer-lined spherical element as the sole moving component, this design provides a robust "fail-safe" for backflow prevention in demanding industrial pumping skids.
The Science of Sphere Dynamics & Seat Interaction
The efficiency of a ball check valve isn't just about moving a ball; it’s about how that ball interacts with the flow profile.
- Optimized Specific Gravity: We calibrate the weight of our sinker balls to match the viscosity of the target media. A ball that is too heavy increases the "cracking pressure," wasting pump energy; a ball that is too light flutters, causing premature seat wear. Our engineering team ensures a precise balance for stable, chatter-free operation.
- The Self-Scouring Seat: Every time the pump cycles, the spherical element rotates randomly. This stochastic motion ensures that the seat is "scoured" by the ball itself, preventing the calcification and mineral scaling that often plague swing-type valves in hard water or chemical process lines.
- Full-Area Porting: Our internal geometry is sculpted to provide a flow path that exceeds the nominal pipe area. This results in an exceptionally low drag coefficient (CdCd), allowing for maximum throughput and helping engineers maintain a favorable NPSH (Net Positive Suction Head) for the primary pump.
| Place of origin | Product name | material | Port size | face to face | Design standard | flanged drilling | Inspection | Working pressure | Application | guarantee period |
| Veyron Valve,Tianjin,China | Ball type check valve | DI body/DI+EPDM ball/DI bonnet/EPDM gasket | DN50-DN300 | DIN3202 F6 | DIN3202 F6 | DIN2501 ,EN1092-2 | DIN3230,EN12266-1 | low and medium pressure | water | 18 month |
